Descripción
Especificaciones
Cockpit
MANUBRIO
Specialized, 6000 series alloy, 6-degree upsweep, 8-degree backsweep. S1-S2: 780 width, 20mm rise; S3-S4: 800 width, 30mm rise; S5-S6: 800 width, 40mm rise
POSTE DE ASIENTO
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 125mm, S2: 150mm, S3: 170mm, S4-S6: 190mm
ASIENTO
Bridge Comp, Hollow Cr-mo rails, S1-S2: 155mm, S3-S6: 143mm
PUÑOS
Specialized Trail Grips
POSTE
Alloy Trail Stem, 35mm bar bore
Transmisión
CADENA
Shimano SLX, M7100, 12-speed
EJE DE CENTRO
Shimano, BB-MT801, Threaded
PEDALIER
Shimano SLX, M7120, 32T ring, 55mm chainline, S1-S3:165mm, S4-S6: 170mm
CASSETTE
Shimano SLX, CS-M7100, 12-speed, 10-51t
PALANCA DE CAMBIOS
Shimano SLX, M7100, 12spd
DESVIADOR TRASERO
Shimano SLX M7100, SGS, 12-speed
Cuadro
CUADRO
M5 Alloy chassis and rear-end, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
ABRAZADERA
Alloy, 38.6mm
SWAT
SWAT internal downtube storage
Suspensión
HORQUILLA
FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset, S1:140mm of travel, S2-S6:150mm of travel
SUSPENSION TRASERA
FOX FLOAT Performance with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever w/ LSR adjustment, S1:210×52.5mm, S2-S6:210x55mm
Frenos
FRENO DELANTERO
TRP Trail EVO, 4-piston caliper, hydraulic disc, 203mm
FRENO TRASERO
TRP Trail EVO, 4-piston caliper, hydraulic disc, S1-S2: 180mm, S3-S6: 203mm
Ruedas y neumáticos
MAZA DELANTERA
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
LLANTA DELANTERA
Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29×2.3″
RAYOS
DT Swiss Industry
NEUMÁTICO TRASERO
Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, S1-S2: 27.5×2.3, S3- S6: 29×2.3″
MAZA TRASERA
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h
LLANTAS
Specialized, hookless alloy, 30mm inner width, tubeless ready, Front: 29, Rear: S1-S2: 27.5, S3- S6: 29
CAMARAS
Standard, Presta valve
