Frameset
Frame
A1 alloy, Sport XC 29 Geometry, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger
Suspension
Fork
SR Suntour XCM 29, coil spring, custom Multi-Circuit damping, quick-release, 46mm offset, 80/90/100mm of travel (size-specific)
Brakes
Rear Brake
Shimano BR-MT200, hydraulic disc, 180mm
Front Brake
Shimano BR-MT200, hydraulic disc, 180mm
Drivetrain
Chainrings
48/32 w/ chainguard
Chain
KMC X9EPT, 9-speed, anti-corrosion coating w/ reusable Missing Link™
Crankset
Stout, forged alloy, 2×9
Rear Derailleur
Shimano Acera, 9-speed
Shift Levers
Shimano Altus, RapidFire Plus, 9-speed
Front Derailleur
microSHIFT FD-M462, 2-speed
Bottom Bracket
Square taper, 73mm, internal bearings
Cassette
SunRace, 9-Speed, 11-36t
Wheels & tires
Spokes
Stainless, 14g
Rear Tire
Fast Trak Sport, 29×2.1″
Front Hub
Shimano, Center Lock™ disc, 9x100mm spacing, quick-release, 28h
Front Tire
Ground Control Sport, 29×2.3″
Inner Tubes
Schrader, 40mm valve
Rims
Specialized Alloy 29, 25mm internal width, disc-specific
Rear Hub
Shimano FH-TX505, Center Lock™ disc, 9x135mm spacing, quick-release, 32h
Cockpit
Handlebars
Specialized Alloy XC minirise, double-butted alloy, 8-degree backsweep, 6-degree upsweep, 10mm rise, 31.8mm
Saddle
Myth Sport, steel rails, 155mm
Seat Binder
Alloy, QR clamp, 34.9mm
SeatPost
Alloy, 12mm offset, 2-bolt clamp, 30.9mm
Stem
Stout 3D-forged alloy, 31.8mm, 6-degree rise
Grips
Specialized MTB Grip, lock-on
